| Specification List | |||
| Item | Specification | With PCM | Material |
| BWX-8L |
External size: 380x380x380mm
Internal size: 260x260x260mm
Capacity :17L
|
PCM : 24.6X24.6X2.5cm - 6pcs Inside size : 200x200x200mm Avaliable Capacity :8L
|
Outside : Oxford bag or PE box
Inside : PU or VPU
|
| BWX-27L |
External size: 460x460x480mm
Internal size: 350x350x350mm
Capacity :42L
|
PCM : 33.7x 33.7x2.5cm - 6pcs
Inside size : 300x300x300mm
Avaliable Capacity :27L
|
Outside : Oxford bag or PE box
Inside : PU or VPU
|
| BWX-50L |
External size: 545x545x545mm
Internal size: 435x435x435mm
Capacity :82L
|
PCM:42x42x3cm - 6 pcs
Inside size : 380x380x3500mm
Avaliable Capacity :50L
|
Outside : Oxford bag or PE box
Inside : PU or VPU
|
| BWX-85L |
External size: 610x610x620mm
Internal size: 500x500x500mm
Capacity :125L
|
PCM :47.7x24x2.5cm - 12 pcs Inside size : 440x440x440mm Avaliable Capacity :85L
|
Outside : Oxford bag or PE box
Inside : PU or VPU
|
| BWX-90L |
External size: 760x540x600mm
Internal size: 630x415x475mm
Capacity :124L
|
PCM :
46.5x31.7x2.5cm - 4pcs
46x41.2x2.5cm - 2pcs
41.2x31.4x2.5cm - 4pcs
Inside size : 580x365x425mm
Avaliable Capacity :90L
|
Outside : Oxford bag or PE box
Inside : PU or VPU
|
|
PU insulation material for 72 hours transport
PU +vip insulation material can hold 96 hours,even 120 hours
The following is the recommended solution according to the requirements
|
|||
PU-VIP material is packaged in a vacuum state as a inner material with a very strong heat insulating property. PU foam moulding, have super thermal insulation, the thermal conducitivity is lower than 0.0025w/m.k., match PCM phase change material can control the temperature precisely for 120H without power supply, enterprises can flexibly choose and reasonable collocation shceme, this can greatly simplify operating, reduce lobor costs. For pharmaceutical logistics enterprises to solve transport problems.
PCM phase change material refers to the material whose state will vary with temperature and provide latent heat and the process of physical properties conversion is called phase change, when the amterial will absorb or release a large amount of latent heat. Our phase change materials temperature can be -40 ~ 100 centi degree, can according to customer request offer design and development. All products using food grade plastic packaging, nont-toxic, safe and environment, meet the requirements of mediccal and food safety.
The temperature range can be 55 degree C,15 degree C,2-8degree C, -10degree C, -15degree C, -18degree C,-20degree C,-25degree C and others, match differenet phase change ice box can keep 48H,72H,96H and others.
